ELAUSYS
AJAX-KNX
AJAX KNX interface
Product code:
AJAX-KNX
Bidirectional KNX gateway for AJAX alarm systems with 96-zone monitoring via Ethernet. Enables real-time security status on KNX bus with automatic scene triggering.
Description
Technical Details
Specification
- Power Supply: External 12-30VDC
- KNX Bus Current: < 16mA @ 29VDC
- Zones Supported: Up to 96
- Area Control: 4 areas with 6 status types each
- Connectivity: Ethernet (RJ45)
- Operating Temperature: +5 to +45C
- Enclosure Size: 2 SU (DIN rail)
- Mounting: DIN Rail
Properties
Properties
| Brand | ELAUSYS |
| Technology | KNX |
| Mounting | DIN Rail |
