THEBEN
P360 DALI-2 S UP WH
theRonda P360 DALI-2 S UP Passive infrared presence sensor, white
Product code:
2080090
Passive infra-red presence sensor for flush-mounted ceiling installation, DALI-2 certified
Description
- Passive infra-red presence sensor for flush-mounted ceiling installation, DALI-2 certified
- Circular detection area 360°, Ø 24 m, (452 m2) at mounting height 3 m
- This device provides information about presence and brightness in the form of a DALI telegram in line with IEC 62386 Part 303/304
- 1 instance for presence
- 3 mixed light measurements
- 4 instances for brightness – integral/interior/centre/window
- Easy to calibrate brightness measurement
- Test mode for checking function and detection area
- Configurable detection sensitivity
- Can be configured via DALI bus or remote control
Technical Details
Specification
Operating voltage: DALI
Installation height: 2 - 10 m
Maximum height: 15 m
Minimum height: 1.7 m
Installation type: Ceiling installation
Power consumption: ≤10 mA
Light measurement: Mixed light measurement
Setting range brightness: 10 - 10000 lx
Max. cable cross section: max. 2 x 2,5 mm²
Size of concealed housing: 55 mm
Switching output: Sensor DALI
Detection range: 452 m² (ø 24 m | 360°)
Detection angle: 360°
Ambient temperature: -15°C ... 50°C
Type of protection: IP 54 (when fitted)
Properties
Properties
| Technology | DALI |
| Brand | THEBEN |
