WEINZIERL
IP Interface 740.2
KNX IP Interface 740.2 wireless secure
Product code:
5537
The KNX IP Interface 740.2 wireless secure serves as a wireless interface to the KNX bus based on WLAN. The device can be used as a programming interface for the ETS® and is a wireless alternative to USB or wired IP interfaces. The bus access via WiFi allows the installer to move freely in the building with his laptop to a large extent.
Description
The KNX IP Interface 740.2 wireless secure has an integrated WiFi access point to which the laptop can connect. Alternatively, the device can be connected to an existing WiFi in client mode. The connection can be made via WPS (WiFi Protected Setup).
The device supports the security standard WPA2 as well as KNX Security.
Power is supplied via the KNX bus.
The device works according to the KNXnet/IP specification. It can be used with the ETS® from version 5.
Technical Details
Specification
Technical data
- Housing: Plastic
- Dimension: 125 x 67 x 31 mm without antenna
- Weight: approx 150g
Operating Controls
- KNX programming button with LED (red)
1 button and 3 LEDs (green)
Indicators
- Operating LED (green)
- Signal LED for WLAN (green)
- Signal LED for KNX/EIB (green)
- Learning/Programming LED (red)
WIFI
- IEEE 802.11b/g/n
- Security: WPA2 (PSK)
Power supply
- KNX Bus approx 22mA
Connectors
- Pluggable screw connector
- SMA for antenna
Properties
Properties
| Brand | WEINZIERL |
| Technology | KNX |
